Textile screen

Screen size

1100x1500mm

1100x1500mm

2600x6000mm

2800x2000mm

2100x5000mm

customized

Textile fabric

Nylon net

Chemical fiber polyester

Chemical fiber polyester

Chemical fiber polyester

Nylon net

Chemical fiber polyester

Light strip type

Addressable & flexible LED strip

Addressable & flexible LED strip

Addressable & flexible LED strip

Addressable & flexible LED strip

Addressable & flexible LED strip

3240

Pixel pitch

15mm

25mm

25mm

25mm

50mm

100mm/50mm/25mm

Pixel resolution

73x100 (7300 LEDs)

44x60 (2640 LEDs)

104x240 (24960 LEDs)

112x80 (8960 LEDs)

5622 LEDsl

width ≤ 2.8 meters, height unlimited

Flagpole length

/

220cm(44*5) (±5cm)

/

/

/

/

LED voltage and current

DC5V/2.5mA

DC5V/2.5mA

DC5V/2.5mA

DC5V/2.5mA

DC5V/2.5mA

DC5V/2.5mA

Connection mode

Parallel circuit, each column plus a transcoding IC board

Parallel circuit, each column plus a transcoding IC board

Parallel circuit, each column plus a transcoding IC board

Parallel circuit, each column plus a transcoding IC board

Parallel circuit, each column plus a transcoding IC board

Parallel circuit, each column plus a transcoding IC board

Control mode

433 wireless synchronous control (a sender can control hundreds of receiver)

433 wireless synchronous control (a sender can control hundreds of receiver)

433 wireless synchronous control(a sender can control hundreds of receiver)

433 wireless synchronous control (a sender can control hundreds of receiver)

433 wireless synchronous control (a sender can control hundreds of receiver)

APP/wireless synchronous control

Communication distance

1000-2000 meters

1000-2000 meters

1000-2000 meters

1000-2000 meters

1000-2000 meters

1000-2000 meters

Power supply mode

High power mobile power supply (last 1-2 hours, depending on the light brightness and content)

High power mobile power supply (last 1-2 hours, depending on the light brightness and content)

High power mobile power supply (last 1-2 hours, depending on the light brightness and content)

High power mobile power supply (last 1-2 hours, depending on the light brightness and content)

High power mobile power supply (last 1-2 hours, depending on the light brightness and content)

DC5V,75W-400W switching power supply/mobile power supply

Weight

3.9kg

2.9kg

14kg

6kg

8.1kg

customized
