TECHNICAL PARAMETERS



Parameter P1.2/1.5/1.8/2/2.5/3 Indoor LED Sphere
Physical Parameter　　 Physical Dot Spacing 1.2/1.5/1.8/2/2.5/3mm±10%
Color of Light-emitting dots 1R1G1B
LEDs SMD1515
Optical Parameters Resolution 2 meters 2688*1297dots
1.5 meters 2064*991dots
1 meter 1392*673dots
Module Gap ≤0.3mm
Module Fixing Method Magnet
Screen Size 1m /3.14㎡
1.5m/7.065㎡
2m/12.56㎡
Screen Weight ≤35kg/㎡
Contrast ratio 3000:01:00
Scanning Method 1/40
White Balance Brightness ≤600cd/㎡
Refresh Frequency  ≥3840Hz
Gray Scale 14bit
Color Temperature 5500K-9500K
Average Power Consumption <240W/㎡
Maximum Power Consumption <800W/㎡
Optimal Viewing Distance 2M～50M
Viewing Angle (H)140°/(V)140°
Power supply AC220V
Application Parameters　 Working Voltage DC4.6V
Ambient Temperature -20℃～+60℃
Relative Humidity 10%-95%
LED Service life ＞100,000 hour
Protection Grade IP31
Maintenance Front Maintain
Installation Method Hoisting/Fixed Mounting
